모형: V1
The file is encrypted. Please fill in the following information to continue accessing it
| Master Kit Current | 100A | 200A | 250A | 300A |
| Number of battery Strings （Lifepo4） | 5S-250S | |||
| Balance Method | Passive balance | |||
| Continuous Discharge current | 100A | 200A | 250A | 300A |
| Other interfaces(Default) | RS485/CAN | |||
| Dispaly interfaces | 4.3inch Lcd Touch screen | |||
| Slave bms(BCU) | 10-16S（selectable） | |||
| Communication protocol |
pylon
|
|||
| Adapt inverter |
DEYE/Goodwe/Solis/Sofar/Megarevo/HYXiPOWER/KINGPAN/Growatt
|
|||
| Overcharge Protection voltage | 1.2V-4.35V(Adjustable) | |||
| Overcharge Release voltage |
1.2V-4.35V(Adjustable)
|
|||
| Overcharge Release time | 2-120S(Adjustable) | |||
| Overdischarge Protection voltage | 1.2V-4.35V(Adjustable) | |||
| Overcharge Recovery voltage | 1.2V-4.35V(Adjustable) | |||
| Temperature Protection | YES | |||
| Short circuit Protection | YES | |||
| Coulometer | YES | |||
| Upgrade | YES | |||
| Operation,alarm,and power indication | YES | |||
| Software | Computer | |||
| Dry Contact | 2 groups | |||
